Autofocus cameras

USB 3.0 color

Does your application demand sharp images despite changing working distances? The Imaging Source has developed its USB 3.0 autofocus color cameras to address just this issue. The software-driven One Push autofocus produces crisp images despite fluctuations in working distance. Highly-sensitive Aptina CMOS sensors deliver excellent image quality - even in less-than-optimal lighting conditions. Additional performance enhancing features of the CMOS sensors include binning, windowing and high-speed readout. The cameras' competitive price point make them an excellent choice for cost-sensitive applications.

  • Resolution: VGA to 10 MP
  • Frame rate: Up to 15 fps
  • Dimensions: 36 x 36 x 30 mm
  • Software-driven One Push autofocus
  • Aptina color CMOS sensors
  • Windowing and high-speed readout
  • Free software for camera control
  • Free barcode SDK for Windows 7/8/10

Windows software: The Imaging Source authors and supports device drivers, software development kits (SDKs), programming samples, extensions, end user software and software tools for Microsoft Windows.

Linux software: The Imaging Source authors and supports open source drivers and end-user software for Linux, the source code of which is released under Apache 2.0 license.

Product code Resolution (max) FPS (max) Format Sensor Type
DFK AFU420-L62 DFK AFU420-L62 7,728×5,368 110 2/3 inch N/A CMOS
DFK AFU130-L53 DFK AFU130-L53 4,128×3,096 30 1/2.5 inch N/A CMOS Exmor
DFK AFUX236-M12 DFK AFUX236-M12 1,920×1,200 54 1/2.8 inch IMX236LQ CMOS
DFK AFUP031-M12 DFK AFUP031-M12 2,592×1,944 15 1/2.5 inch MT9P031 CMOS
DFK AFUJ003-M12 DFK AFUJ003-M12 3,856×2,764 7 1/2.3 inch MT9J003 CMOS
Subject to change

About The Imaging Source

Established in 1990, The Imaging Source is one of the leading manufacturers of industrial cameras, frame grabbers and video converters for production automation, quality assurance, logistics, medicine, science and security.

Our comprehensive range of cameras with USB 3.0, USB 2.0, GigE, FireWire 400, FireWire 800 interfaces and other machine vision products are renowned for being innovative, high quality and for constantly meeting the performance requirements of demanding applications.

Automated Imaging Association ISO 9001:2015 certified
