Board cameras
GigE color
Characterized by small PCB dimensions of 45 x 45 x 20 mm and an unbeatable price point, The Imaging Source GigE color board cameras are the go-to cameras for a wide variety of industrial automation, quality assurance, surveillance and medical applications. Ideally suited to cost- and space-sensitive projects, GigE technology offers the additional benefits of unsurpassed data transmission and cable lengths of up to 100 meters. Performance enhancing features available on the CMOS cameras such as binning, windowing and high-speed readout, dramatically reduce image noise levels.
- Resolution: VGA to 5 MP
- Frame rate: Up to 36 fps
- Dimensions: 45 x 45 x 20 mm
- GigE interface with PoE
- Color CMOS and CCD sensors
- M12 lens compatibility
- Free software for camera control
- Free barcode SDK for Windows 7/8/10
Windows software: The Imaging Source authors and supports device drivers, software development kits (SDKs), programming samples, extensions, end user software and software tools for Microsoft Windows.
Linux software: The Imaging Source authors and supports open source drivers and end-user software for Linux, the source code of which is released under Apache 2.0 license.
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Sensor type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
DFM 25G445-ML | 1.2 MP | 1,280×960 | 30 | 1/3 inch | ICX445AQA | CCD | global | ||
|
DFM 25GX236-ML | 2.3 MP | 1,920×1,200 | 41 | 1/2.8 inch | IMX236LQJ | CMOS Exmor | rolling | ||
|
DFM 25GP031-ML | 5 MP | 2,592×1,944 | 15 | 1/2.5 inch | MT9P031 | CMOS | rolling | ||
| Subject to change. | ||||||||||
About The Imaging Source
Established in 1988, The Imaging Source is one of the leading manufacturers of industrial cameras, video converters and embedded vision components for factory automation, quality assurance, medicine, science, security and a variety of other markets.
Our comprehensive range of cameras with USB 3.1, USB 3.0, USB 2.0, GigE, MIPI interfaces and other innovative machine vision products are renowned for their high quality and ability to meet the performance requirements of demanding applications.
