Board cameras

USB 2.0 color

The Imaging Source USB 2.0 color board cameras feature Sony and Aptina CCD and CMOS sensors - providing exceptional image quality even in poor or fluctuating lighting conditions. These cameras measure only 50 x 50 x 56 mm and their board-level form creates maximum flexibility for a wide range of applications where space is at a premium. Our USB 2.0 CMOS board cameras feature binning, windowing and high-speed readout - delivering a dramatic reduction in image noise levels. The included software allows for the adjustment of gain, exposure, frame rate and white balance. Specific models are available with a variety of input, output, strobe and trigger options.

  • Resolution: VGA to 5 MP
  • Frame rate: Up to 76 fps
  • Dimensions: Starting at 30 x 30 x 15 mm
  • Wide range of color CMOS and CCD sensors
  • M12 lens compatibility
  • Free software for camera control
  • Free barcode SDK for Windows 7/8/10

Windows software: The Imaging Source authors and supports device drivers, software development kits (SDKs), programming samples, extensions, end user software and software tools for Microsoft Windows.

Linux software: The Imaging Source authors and supports open source drivers and end-user software for Linux, the source code of which is released under Apache 2.0 license.

Product code Resolution (max) FPS (max) Format Sensor Trigger I/Os Type Shutter
DFM 22BUC03-ML DFM 22BUC03-ML 744×480 76 1/3 inch MT9V024 CMOS global
DFM 42BUC03-ML DFM 42BUC03-ML 1,280×960 25 1/3 inch MT9M021 CMOS global
DFM 61BUC02-ML DFM 61BUC02-ML 2,048×1,536 10 1/2 inch MT9T031 CMOS global
DFM 72BUC02-ML DFM 72BUC02-ML 2,592×1,944 6 1/2.5 inch MT9P006 CMOS rolling
DFM 73AUC04-ML DFM 73AUC04-ML 2,592×1,944 10 1/4 inch OV5640 CMOS rolling
Subject to change
