Board cameras

USB 3.0 color

The Imaging Source USB 3.0 CMOS color board cameras are a high-performance and cost-effective solution for many OEM applications. These versatile board level cameras produce a high-quality video stream and high frame rates. To meet the requirements of your unique application, we can also customize our standard cameras. With our comprehensive library of free imaging software the user can adjust settings such as gain, exposure time and frame rate or allow the camera make these adjustments automatically. Easy integration and in-house customer support ensure maximum performance for your application.

  • Resolution: VGA to 10 MP
  • Frame rate: Up to 15 fps
  • Dimensions: 30 x 30 x 18 mm
  • Aptina color CMOS sensors
  • Windowing and high-speed readout
  • M12 lens compatibility
  • Free software for camera control
  • Free barcode SDK for Windows 7/8/10

Windows software: The Imaging Source authors and supports device drivers, software development kits (SDKs), programming samples, extensions, end user software and software tools for Microsoft Windows.

Linux software: The Imaging Source authors and supports open source drivers and end-user software for Linux, the source code of which is released under Apache 2.0 license.

Product code Resolution (max) FPS (max) Format Sensor Trigger I/Os Type Shutter
DFM 27UR0135-ML DFM 27UR0135-ML 1,280×960 60 1/3 inch AR0135 CMOS global
DFM 27UP006-ML DFM 27UP006-ML 2,592×1,944 15 1/2.5 inch MT9P006 CMOS rolling
DFM 24UP031-ML DFM 24UP031-ML 2,592×1,944 15 1/2.5 inch MT9P031 CMOS rolling
DFM 27UJ003-ML DFM 27UJ003-ML 3,856×2,764 7 1/2.3 inch MT9J003 CMOS rolling
DFM 24UJ003-ML DFM 24UJ003-ML 3,856×2,764 7 1/2.3 inch MT9J003 CMOS rolling
Subject to change
