Industrial cameras
USB 2.0 monochrome
The Imaging Source One4all series of CMOS monochrome cameras is the perfect solution for many industrial automation, quality assurance, security, surveillance and scientific applications. Using Aptina CMOS technology, our USB 2.0 industrial monochrome cameras feature binning, windowing and high-speed readout with reduced image noise levels and wide dynamic range. An unbeatable price point and reliability are key characteristics of The Imaging Source One4all CMOS cameras. USB 2.0 CCD monochrome cameras are shipped with sensitive Sony CCD sensors and are available in a variety of resolutions and speeds which deliver exceptional image quality. Both CMOS and CCD cameras feature a compact, robust design which allows them to meet the requirements of even the most demanding applications.
- Resolution: VGA to 5 MP
- Frame rate: Up to 76 fps
- Dimensions: Starting at 36 x 36 x 25 mm
- Wide range of monochrome CMOS and CCD sensors
- Free software for camera control
- Free barcode SDK for Windows 7/8/10
Windows software: The Imaging Source authors and supports device drivers, software development kits (SDKs), programming samples, extensions, end user software and software tools for Microsoft Windows.
Linux software: The Imaging Source authors and supports open source drivers and end-user software for Linux, the source code of which is released under Apache 2.0 license.
USB 2.0 CMOS monochrome industrial cameras
| Product code | Resolution (max) | FPS (max) | Format | Sensor | Trigger | I/Os | Type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|
 |
DMK 22BUC03 | 744×480 (0.4 MP) | 76 | 1/3 inch | MT9V024 | CMOS | global | ||
|
DMK 22AUC03 | 744×480 (0.4 MP) | 76 | 1/3 inch | MT9V024 | CMOS | global | ||
|
DMK 42BUC03 | 1,280×960 (1.2 MP) | 25 | 1/3 inch | MT9M021 | CMOS | global | ||
|
DMK 42AUC03 | 1,280×960 (1.2 MP) | 25 | 1/3 inch | MT9M021 | CMOS | global | ||
|
DMK 72AUC02 | 2,592×1,944 (5 MP) | 6 | 1/2.5 inch | MT9P031 | CMOS | rolling | ||
|
DMK 72BUC02 | 2,592×1,944 (5 MP) | 6 | 1/2.5 inch | MT9P031 | CMOS | rolling | ||
| Subject to change. | |||||||||
USB 2.0 CCD monochrome industrial cameras
| Product code | Resolution (max) | FPS (max) | Format | Sensor | Trigger | I/Os | Type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|
 |
DMK 31BU03 | 1,024×768 (0.8 MP) | 30 | 1/3 inch | ICX204AL | CCD | global | ||
|
DMK 31AU03 | 1,024×768 (0.8 MP) | 30 | 1/3 inch | ICX204AL | CCD | global | ||
|
DMK 31BU03.H | 1,024×768 (0.8 MP) | 30 | 1/3 inch | ICX204AL | CCD | global | ||
|
DMK 41BU02.H | 1,280×960 (1.2 MP) | 15 | 1/2 inch | ICX205AL | CCD | global | ||
|
DMK 41AU02 | 1,280×960 (1.2 MP) | 15 | 1/2 inch | ICX205AL | CCD | global | ||
|
DMK 41BU02 | 1,280×960 (1.2 MP) | 15 | 1/2 inch | ICX205AL | CCD | global | ||
| Subject to change. | |||||||||
