Industrial cameras
USB 3.1 monochrome
The Imaging Source "37" and "38 series" industrial cameras are equipped with highly-sensitive, low-noise Sony Pregius, Pregius S or STARVIS sensors which deliver outstanding image quality and NIR sensitivity. The USB3 Vision standard (USB 3.1- Gen. 1), ensures stability and compatibility for easy integration and flexible configuration. Even at high frame rates, "38 Series" cameras deliver distortion-free images and are well-suited for applications such as intelligent traffic systems (ITS), automated optical inspection (AOI) and microscopy.
- Resolution: VGA to 24.5 MP
- Frame rate: Up to 539 fps
- Dimensions: 29 x 44 x 60
- Sensor: Sony Pregius CMOS Global Shutter
- Free software for camera control
- Free barcode SDK for Windows 7/8/10
Windows software: The Imaging Source authors and supports device drivers, software development kits (SDKs), programming samples, extensions, end user software and software tools for Microsoft Windows.
Linux software: The Imaging Source authors and supports open source drivers and end-user software for Linux, the source code of which is released under Apache 2.0 license.
38 series - USB 3.1 monochrome industrial cameras
- Compatible to UVC and USB3 Vision
- Sony Pregius and Pregius S CMOS sensors
- Onboard image pre-processing
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Sensor type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
DMK 38UX267 | 8.8 MP | 4,096×2,160 | 35 | 1 inch | IMX267 | CMOS Pregius | global | ||
|
DMK 38UX255 | 8.8 MP | 4,096×2,160 | 42 | 1 inch | IMX255 | CMOS Pregius | global | ||
|
DMK 38UX304 | 12.3 MP | 4,096×3,000 | 26 | 1.1 inch | IMX304 | CMOS Pregius | global | ||
|
DMK 38UX253 | 12.3 MP | 4,096×3,000 | 30 | 1.1 inch | IMX253 | CMOS Pregius | global | ||
|
DMK 38UX542 | 16.1 MP | 5,320×3,032 | 23 | 1.1 inch | IMX542 | CMOS Pregius S | global | ||
|
DMK 38UX541 | 20.3 MP | 4,504×4,504 | 18 | 1.1 inch | IMX541 | CMOS Pregius S | global | ||
|
DMK 38UX540 | 24.5 MP | 5,320×4,600 | 15 | 1.2 inch | IMX540 | CMOS Pregius S | global | ||
| Subject to change. | ||||||||||
37 A series - USB 3.1 monochrome industrial cameras
- Reversible Type-C port connection
- Sony STARVIS and Pregius CMOS sensors
- Single-board cameras
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Sensor type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
DMK 37AUX287 | 0.4 MP | 720×540 | 539 | 1/2.9 inch | IMX287 | CMOS Pregius | global | ||
|
DMK 37AUX273 | 1.6 MP | 1,440×1,080 | 238 | 1/2.9 inch | IMX273 | CMOS Pregius | global | ||
|
DMK 37AUX290 | 2.1 MP | 1,920×1,080 | 143 | 1/2.8 inch | IMX290 | CMOS STARVIS | rolling | ||
 |
DMK 37AUX252 | 3.1 MP | 2,048×1,536 | 119 | 1/1.8 inch | IMX252 | CMOS Pregius | global | ||
|
DMK 37AUX265 | 3.1 MP | 2,048×1,536 | 60 | 1/1.8 inch | IMX265 | CMOS Pregius | global | ||
|
DMK 37AUX250 | 5 MP | 2,448×2,048 | 75 | 2/3 inch | IMX250 | CMOS Pregius | global | ||
|
DMK 37AUX264 | 5 MP | 2,448×2,048 | 38 | 2/3 inch | IMX264 | CMOS Pregius | global | ||
|
DMK 37AUX178 | 6.3 MP | 3,072×2,048 | 60 | 1/1.8 inch | IMX178 | CMOS STARVIS | rolling | ||
|
DMK 37AUX226 | 12 MP | 4,000×3,000 | 30 | 1/1.7 inch | IMX226 | CMOS STARVIS | rolling | ||
| Subject to change. | ||||||||||
37 B series - USB 3.1 monochrome industrial cameras
- Reversible Type-C port connection
- Sony STARVIS and Pregius CMOS sensors
- With trigger and I/O
- Single-board cameras
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Sensor type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
DMK 37BUX287 | 0.4 MP | 720×540 | 539 | 1/2.9 inch | IMX287 | CMOS Pregius | global | ||
|
DMK 37BUX273 | 1.6 MP | 1,440×1,080 | 238 | 1/2.9 inch | IMX273 | CMOS Pregius | global | ||
|
DMK 37BUX290 | 2.1 MP | 1,920×1,080 | 143 | 1/2.8 inch | IMX290 | CMOS STARVIS | rolling | ||
 |
DMK 37BUX252 | 3.1 MP | 2,048×1,536 | 119 | 1/1.8 inch | IMX252 | CMOS Pregius | global | ||
|
DMK 37BUX265 | 3.1 MP | 2,048×1,536 | 60 | 1/1.8 inch | IMX265 | CMOS Pregius | global | ||
|
DMK 37BUX250 | 5 MP | 2,448×2,048 | 75 | 2/3 inch | IMX250 | CMOS Pregius | global | ||
|
DMK 37BUX264 | 5 MP | 2,448×2,048 | 38 | 2/3 inch | IMX264 | CMOS Pregius | global | ||
|
DMK 37BUX178 | 6.3 MP | 3,072×2,048 | 60 | 1/1.8 inch | IMX178 | CMOS STARVIS | rolling | ||
|
DMK 37BUX226 | 12 MP | 4,000×3,000 | 30 | 1/1.7 inch | IMX226 | CMOS STARVIS | rolling | ||
| Subject to change. | ||||||||||
About The Imaging Source
Established in 1990, The Imaging Source is one of the leading manufacturers of industrial cameras, video converters and embedded vision components for factory automation, quality assurance, medicine, science, security and a variety of other markets.
Our comprehensive range of cameras with USB 3.1, USB 3.0, USB 2.0, GigE, MIPI interfaces and other innovative machine vision products are renowned for their high quality and ability to meet the performance requirements of demanding applications.
