Autofocus cameras
USB 2.0 monochrome autofocus cameras
In some machine vision system scenarios, maintaining exact working distances are virtually impossible. For these applications, The Imaging Source offers its USB 2.0 autofocus monochrome cameras. Using software-driven One Push autofocus, the cameras produce sharp images despite fluctuations in working distance. The Aptina CMOS monochrome sensors are highly-sensitive and deliver excellent image quality - even in less-than-optimal lighting conditions. Additional image control functions such as gain and exposure time can be adjusted automatically or manually via the included imaging software. The cameras' compact dimensions ensure easy integration into existing applications.
- Resolution: VGA to 5 MP
- Frame rate: Up to 76 fps
- Dimensions: 36 x 36 x 25 mm
- Software-driven One Push autofocus
- Aptina monochrome CMOS sensors
- Windowing and high-speed readout
- Free software for camera control
- Free barcode SDK for Windows 7/8/10
Windows software: The Imaging Source authors and supports device drivers, software development kits (SDKs), programming samples, extensions, end user software and software tools for Microsoft Windows.
Linux software: The Imaging Source authors and supports open source drivers and end-user software for Linux, the source code of which is released under Apache 2.0 license.
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Sensor type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
DMK 22AUC03-F | 0.4 MP | 744×480 | 76 | 1/3 inch | MT9V024 | CMOS | global | ||
|
DMK 72AUC02-F | 5 MP | 2,592×1,944 | 6 | 1/2.5 inch | MT9P031 | CMOS | rolling | ||
| Subject to change. | ||||||||||
About The Imaging Source
Established in 1990, The Imaging Source is one of the leading manufacturers of industrial cameras, video converters and embedded vision components for factory automation, quality assurance, medicine, science, security and a variety of other markets.
Our comprehensive range of cameras with USB 3.1, USB 3.0, USB 2.0, GigE, MIPI interfaces and other innovative machine vision products are renowned for their high quality and ability to meet the performance requirements of demanding applications.
