DMM 42BUC03-ML
USB 2.0 monochrome board camera
- 1/3 inch ON Semiconductor CMOS sensor (MT9M021)
- 1,280×960 (1.2 MP), up to 25 fps
- Global shutter
- Trigger and I/O inputs
- Manufactured by The Imaging Source
- Windows software included
⋯
⋯ ⋯
| General behavior | |
| Dynamic range | 8 bit |
| Video formats @ frame rate (maximum) | 1,280×960 (1.2 MP) Y800 @ 25 fps
1,280×960 (1.2 MP) RGB24 @ 25 fps |
| Interface (optical) | |
| Sensor type | CMOS |
| Sensor specification | ON Semiconductor MT9M021 |
| Shutter | global |
| Format | 1/3 inch |
| Pixel size | H: 3.75 µm, V: 3.75 µm |
| Lens mount | M12x0.5 |
| Interface (electrical) | |
| Interface | USB 2.0 (forwards compatible) |
| Supply voltage | 4.5 VDC to 5.5 VDC |
| Current consumption | approx 250 mA @ 5 VDC |
| Auto iris control | |
| Trigger | |
| I/Os | |
| Interface (mechanical) | |
| Dimensions | H: 30 mm, W: 30 mm, L: 15 mm |
| Mass | 7 g |
| Adjustments | |
| Shutter | 1/10,000 s to 30 s |
| Environmental | |
| Temperature (operating) | -5 °C to 45 °C |
| Temperature (storage) | -20 °C to 60 °C |
| Humidity (operating) | 20 % to 80 % (non-condensing) |
| Humidity (storage) | 20 % to 95 % (non-condensing) |
| Subject to change. | |
| Technical Reference Manuals | |||
 |
DMM 42BUC03-ML Technical Reference Manual | 1.1 | April 23, 2019 |
| Whitepapers about Cameras | |||
 |
Industrial Cameras: USB CMOS - 22, 42 and 72 Series - Pico Blade USB | 1.5 | July 1, 2014 |
| Datasheets for CMOS Sensors | |||
 |
Datasheet for ON Semiconductor MT9M021 CMOS Sensor | 1.1 | January 31, 2012 |
| Subject to change. | |||
| Cables | ||
 |
CA-USB20-AmB-BLS/5 | USB 2.0 cable, 5 m in length |
| Subject to change. | ||
