Industrial cameras
USB 3.0 monochrome
The Imaging Source USB 3.0 monochrome industrial cameras feature the latest CMOS technology from Sony and onsemi. These cameras are available with a variety of input/output strobe and trigger options via an external Hirose port. A highly versatile imaging solution, these cameras are competitively priced and available with resolutions from VGA to 20 megapixels and frame rates of up to 539 fps. Macro, wide-angle and tele lenses are also available as accessories. Our comprehensive library of software, available free of charge with all our products, and in-house customer support ensure maximum performance for your application.
- Resolution: VGA to 20 MP
- Frame rate: Up to 539 fps
- Dimensions: 29 x 29 x 43 and 36 x 36 x 25 mm
- Wide range of monochrome CMOS and CCD sensors
- Free software for camera control
- Free barcode SDK for Windows 7/8/10
Windows software: The Imaging Source authors and supports device drivers, software development kits (SDKs), programming samples, extensions, end user software and software tools for Microsoft Windows.
Linux software: The Imaging Source authors and supports open source drivers and end-user software for Linux, the source code of which is released under Apache 2.0 license.
33 series - USB 3.0 monochrome industrial cameras
- Compatible to UVC and USB3 Vision
- Sony Pregius and STARVIS sensors
- Onboard image pre-processing
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
DMK 33UX287 | 0.4 MP | 720×540 | 539 | 1/2.9 inch | IMX287 | CMOS Pregius | global | ||
|
DMK 33UP1300 | 1.3 MP | 1,280×1,024 | 210 | 1/2 inch | PYTHON 1300 | CMOS Python | global | ||
|
DMK 33UX273 | 1.6 MP | 1,440×1,080 | 238 | 1/2.9 inch | IMX273 | CMOS Pregius | global | ||
|
DMK 33UX290 | 2.1 MP | 1,920×1,080 | 143 | 1/2.8 inch | IMX290 | CMOS STARVIS | rolling | ||
|
DMK 33UP2000 | 2.3 MP | 1,920×1,200 | 129 | 2/3 inch | PYTHON 2000 | CMOS Python | global | ||
|
DMK 33UX174 | 2.3 MP | 1,920×1,200 | 162 | 1/1.2 inch | IMX174 | CMOS Pregius | global | ||
|
DMK 33UX249 | 2.3 MP | 1,920×1,200 | 48 | 1/1.2 inch | IMX249 | CMOS Pregius | global | ||
|
DMK 33UX265 | 3.1 MP | 2,048×1,536 | 60 | 1/1.8 inch | IMX265 | CMOS Pregius | global | ||
|
DMK 33UX252 | 3.1 MP | 2,048×1,536 | 120 | 1/1.8 inch | IMX252 | CMOS Pregius | global | ||
|
DMK 33UX264 | 5 MP | 2,448×2,048 | 38 | 2/3 inch | IMX264 | CMOS Pregius | global | ||
|
DMK 33UR0521 | 5 MP | 2,592×1,944 | 60 | 1/2.5 inch | AR0521 | CMOS | rolling | ||
|
DMK 33UX250 | 5 MP | 2,448×2,048 | 75 | 2/3 inch | IMX250 | CMOS Pregius | global | ||
|
DMK 33UP5000 | 5.3 MP | 2,592×2,048 | 60 | 1 inch | PYTHON 5000 | CMOS Python | global | ||
|
DMK 33UX178 | 6.3 MP | 3,072×2,048 | 60 | 1/1.8 inch | IMX178 | CMOS STARVIS | rolling | ||
|
DMK 33UJ003 | 10.7 MP | 3,856×2,764 | 14 | 1/2.3 inch | MT9J003 | CMOS | rolling | ||
|
DMK 33UX226 | 12 MP | 4,000×3,000 | 30 | 1/1.7 inch | IMX226 | CMOS STARVIS | rolling | ||
|
DMK 33UX183 | 20 MP | 5,472×3,648 | 18 | 1 inch | IMX183 | CMOS Exmor | rolling | ||
| Subject to change. | ||||||||||
23 series - USB 3.0 monochrome industrial cameras
- Compact housing
- Aptina CMOS sensors
- Sony CMOS and CCD sensors
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|---|
|
DMK 23U618 | 0.3 MP | 640×480 | 120 | 1/4 inch | ICX618ALA | CCD | global | ||
|
DMK 23UV024 | 0.4 MP | 752×480 | 100 | 1/3 inch | MT9V024 | CMOS | global | ||
|
DMK 23UM021 | 1.2 MP | 1,280×960 | 60 | 1/3 inch | MT9M021 | CMOS | global | ||
|
DMK 23U445 | 1.2 MP | 1,280×960 | 30 | 1/3 inch | ICX445ALA | CCD | global | ||
|
DMK 23UP1300 | 1.3 MP | 1,280×1,024 | 95 | 1/2 inch | PYTHON 1300 | CMOS Python | global | ||
|
DMK 23U274 | 1.9 MP | 1,600×1,200 | 20 | 1/1.8 inch | ICX274AL | CCD | global | ||
|
DMK 23UX236 | 2.3 MP | 1,920×1,200 | 54 | 1/2.8 inch | IMX236LLJ | CMOS Exmor | rolling | ||
|
DMK 23UX174 | 2.3 MP | 1,920×1,200 | 54 | 1/1.2 inch | IMX174LLJ | CMOS Pregius | global | ||
|
DMK 23UX249 | 2.3 MP | 1,920×1,200 | 30 | 1/1.2 inch | IMX249LLJ | CMOS Pregius | global | ||
|
DMK 23UP031 | 5 MP | 2,592×1,944 | 15 | 1/2.5 inch | MT9P031 | CMOS | rolling | ||
| Subject to change. | ||||||||||
27 series - USB 3.0 monochrome industrial cameras
- Flat compact housing
- 5 and 10 megapixel
- Available as 1 PCB
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Type | Shutter | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
DMK 27AUR0135 | 1.2 MP | 1,280×960 | 60 | 1/3 inch | AR0135 | CMOS | global | ||
|
DMK 27BUR0135 | 1.2 MP | 1,280×960 | 60 | 1/3 inch | AR0135 | CMOS | global | ||
|
DMK 27AUP031 | 5 MP | 2,592×1,944 | 15 | 1/2.5 inch | MT9P031 | CMOS | rolling | ||
|
DMK 27BUP031 | 5 MP | 2,592×1,944 | 15 | 1/2.5 inch | MT9P031 | CMOS | rolling | ||
|
DMK 27AUJ003 | 10.7 MP | 3,856×2,764 | 7 | 1/2.3 inch | MT9J003 | CMOS | rolling | ||
|
DMK 27BUJ003 | 10.7 MP | 3,856×2,764 | 7 | 1/2.3 inch | MT9J003 | CMOS | rolling | ||
| Subject to change. | ||||||||||
