| 特性概要 | |
| 動態範圍 | 12 bit |
| 解析度 | 2,592×1,944 (5 MP) |
| 幀率 | 22 fps |
| 視訊輸出格式 | 8-Bit Bayer (GR), 12-Bit Bayer Packed (GR), 16-Bit Bayer (GR), YUV 4:2:2, YUV 4:1:1, YUV 4:1:1, RGB24, 8-Bit Monochrome, 12-Bit Packed Monochrome, 16-Bit Monochrome |
| 介面 (光學) | |
| 感測器類型 | CMOS |
| 感測器規格 | onsemi AR0521 |
| 快門 | 捲簾 |
| 規格 | 1/2.5 inch |
| 畫素 | 水平: 2.2 µm, 垂直: 2.2 µm |
| 鏡頭接口 | C |
| 介面 (電子) | |
| 介面 | GigE |
| 供應電壓 | 8 VDC 至 25 VDC 或乙太網路供電 48 VDC 至 56 VDC |
| 功耗: | 2.3 W 乙太網路供電 |
| 消耗電流 | 大約 150 mA @ 12 VDC |
| 自動光圈控制 | |
| 觸發器 | |
| 輸入/輸出 | |
| 介面 (機械) | |
| 尺寸 | 高: 29 mm, 寬: 29 mm, 長: 44 mm |
| 重量 | 63 g |
| 調整 | |
| 快門 | 100 µs 至 10 s |
| 增益 | 0 dB 至 11.81 dB |
| 環境 | |
| 外殼溫度 (工作) | 0 °C 至 55 °C |
| 溫度 (儲存) | -20 °C 至 80 °C |
| 濕度 (作業) | 20 % 至 80 % (非冷凝) |
| 濕度 (儲存) | 20 % 至 95 % (非冷凝) |
| 依實際情形調整更動 | |
 |
ViC 43GR0521 Data Sheet | 新的 | 1.0 | 7月 2025 |
 |
Industrial Cameras Operating Instructions | 新的 | 1.6 | 7月 2025 |
 |
ViC 43GR0521 Technical Reference Manual | 新的 | 1.0 | 7月 2025 |
 |
The Imaging Source Catalog | 新的 | 2025.08 | 8月 2025 |
 |
Datasheet for onsemi AR0521 CMOS Sensor | | 1.0 | 2月 2023 |
 |
GigE Vision 相機 GenTL Producer (Windows / Linux) | | 1.4.1.966 |  |
5月 2025 |
 |
USB3 Vision 相機 GenTL Producer (Windows / Linux) | | 1.4.1.733 | |
5月 2025 |
 |
非 GenICam 相機的 GenTL Producer (DirectShow) | | 2.0.0.390 | |
3月 2024 |
 |
非 GenICam 相機的 GenTL Producer (V4L2) | | 1.0.0.144 | |
1月 2025 |
 |
GigE相機驅動程式 | | 3.8.0.4597 | |
2月 2022 |
 |
IC Imaging Control 4 SDK (Windows / Linux) | | 1.3.0.3125 | |
5月 2025 |
 |
IC Imaging Control C++類庫(C++項目適用) | | 3.5.7 | |
12月 2022 |
 |
IC Imaging Control .NET元件(C#和VB.NET項目適用) | | 3.5.7 | |
12月 2022 |
 |
IC Imaging Control C 範例 | | 3.4.0.51 | |
11月 2017 |
 |
IC Barcode - 1D and 2D Barcode Reader for IC Imaging Control | | 1.1.0.704 | |
3月 2021 |
 |
IC Barcode for Linux AMD64/x64 | | 1.1.0.703 |  |
3月 2021 |
 |
IC Barcode for Linux ARM 64 Bit | | 1.1.0.703 | |
3月 2021 |
 |
tiscamera Camera Library for Ubuntu 18.04 and 22.04 64 Bit on x64 Architecture | | 1.1.1.4142 | |
4月 2023 |
 |
tiscamera Camera Library for Ubuntu 20.04 64 Bit on x64 Architecture | | 1.1.1.4142 | |
4月 2023 |
 |
tiscamera Camera Library for ARM 64 Ubuntu 18.04 and 22.04 64 Bit | | 1.1.1.4142 | |
4月 2023 |
 |
tiscamera Camera Library for ARM 64 Ubuntu 20.04 64 Bit | | 1.1.1.4142 | |
4月 2023 |
 |
tiscamera Development Package | | 1.1.0.4139 | |
4月 2023 |
 |
IC Capture - Image Acquisition and Image Measurement | | 4.0.1.539 | |
5月 2025 |
 |
IC Measure - 手動式螢幕測量和圖像擷取 | | 4.0.0.219 | |
5月 2024 |
 |
IC Measure for AMD 64 Linux | | 3.0.0.503 | |
6月 2023 |
 |
IC Measure for ARM 64 Linux | | 3.0.0.503 | |
6月 2023 |
 |
tcamdutils for Linux on x64 | | 1.0.0.560 | |
6月 2022 |
 |
tcamdutils for Linux ARM64 | | 1.0.0.560 | |
6月 2022 |
 |
tcamdutils-cuda GPU Enhanced Processing on NVIDIA® Tegra | | 1.2.0.397 | |
7月 2022 |
 |
tcamtegrasrc for MIPI and FPD Link Cameras on NVIDIA® Tegra | | 1.2.0.398 | |
7月 2022 |
 |
tiscamera Linux 32 Bit Camera Library for ARMHF Architecture | | 1.1.0.4139 | |
4月 2023 |
 |
tcamdutils 32 Bit for Raspberry PI OS | | 1.0.0.560 | |
6月 2022 |
 |
Raspberry PI GStreamer Source for The Imaging Source MIPI Cameras | | 1.3.0.662 | |
1月 2023 |
 |
tcamprop for Raspberry PI OS | | 0.1.0 | |
3月 2021 |
|
tiscamera Camera Library for Ubuntu 18.04 and 22.04 64 Bit on x64 Architecture | | 1.1.1.4142 | |
4月 2023 |
|
tiscamera Camera Library for Ubuntu 20.04 64 Bit on x64 Architecture | | 1.1.1.4142 | |
4月 2023 |
|
tiscamera Camera Library for ARM 64 Ubuntu 18.04 and 22.04 64 Bit | | 1.1.1.4142 | |
4月 2023 |
|
tiscamera Camera Library for ARM 64 Ubuntu 20.04 64 Bit | | 1.1.1.4142 | |
4月 2023 |
 |
IC Imaging Control TWAIN驅動擴充套件 | | 3.0.0.144 | |
2月 2021 |
 |
Cognex VisionPro AIK擴充套件 | | 3.4.2.0 | |
7月 2019 |
 |
IC Imaging Control LabVIEW擴充套件 | | 3.4.0.41 | |
9月 2019 |
 |
IC Imaging Control Matlab R2013b,R2014擴充套件 | | 3.4.0.58 | |
11月 2017 |
 |
NeuroCheck 6.2 ─ IC NeuroCheck Driver | | 1.1.0.122 | |
6月 2021 |
 |
IC Express - High-speed image capture into single image files | | 1.1.0.23 | |
7月 2019 |
 |
Processor Idle State Manager | | 2.2.0.2 | |
3月 2014 |
 |
Hot Pixel Correction (畫素修復工具) | | 4.0. | |
7月 2019 |
 |
IC Fullscreen Presenter - Video display on the entire screen | | 1.3.0.0 | |
1月 2023 |
 |
IC Line Profiler | | 1.1.0.9 | |
8月 2014 |
 |
Footswitch software for IC Capture | | 1.0.0.9 | |
9月 2014 |
 |
Demo Image for NVIDIA® Jetson Nano™ Development Kits | | 1.0.5 | |
2月 2022 |
 |
Demo Image for NVIDIA® Jetson Xavier NX™ Development Kits | | 1.0.5 | |
2月 2022 |
 |
Demo Image for Raspberry Pi 4 B Development Kits | | 1.0.0 | |
3月 2021 |
 |
DFG/USB2-lt轉換器驅動程式 | | 1.2.0.17 | |
8月 2011 |
 |
DFG/HDSDI驅動程式 | | 2.9.5 | |
4月 2018 |
 |
IEEE1394b相機驅動程式 | | 5.0.13.327 | |
3月 2014 |
 |
IEEE1394a相機驅動程式 | | 4.4.0.1 | |
6月 2011 |
 |
Video-to-FireWire轉換器驅動程式 | | 4.2.0.1 | |
2月 2011 |
 |
Scan2Docx | | 1.1.0.883 | |
2月 2015 |
 |
Scan2Docx OCR | | 1.1.0.883 | |
2月 2015 |
 |
IC 3D - 人性化三維校正；深度估測及三維可視化 | | 1.1 | |
8月 2018 |
 |
IC 3D SDK - 透過C及C++程式資料庫進行立體深度估測 | | 1.1 | |
8月 2018 |
 |
IC Imaging Control ActiveX | | 3.2.0.0 | |
7月 2012 |
 |
IC Imaging Control ActiveX Runtime Setup | | 3.2.0.0 | |
7月 2012 |
 |
IC Imaging Control - 範例 | | 3.3 | |
8月 2014 |
 |
IC Imaging Control Matlab 10.0 R2010擴充套件 | | 1.1.0.0 | |
7月 2013 |
 |
NeuroCheck 6.0 ─ IC NeuroCheck Driver | | 1.0.0.51 | |
9月 2014 |
 |
NeuroCheck 6.1 ─ IC NeuroCheck Driver | | 1.1.0.69 | |
5月 2018 |
 |
MIPI Sensor Drivers for NVIDIA® JetPack Version 4.4 | | 2.2.11-1 | |
12月 2021 |
 |
MIPI Sensor Drivers for NVIDIA® JetPack Version 4.4.1 | | 2.2.11-1 | |
12月 2021 |
 |
tis-tegra-filters for NVIDIA® Tegra | | 1.1.1 | |
12月 2021 |
