| 特性概要 | |
| 灵敏度 | 0.015 lx |
| 动态范围 | 8/12 bit |
| 视频格式 @ 帧率 (最大) | 1,280×960 (1.2 MP) Y800 @ 60 fps 1,280×960 (1.2 MP) Y16 @ 30 fps |
| 接口 (光学) | |
| 传感器类型 | CMOS |
| 传感器规格 | onsemi MT9M021 |
| 快门 | 全局 |
| 规格 | 1/3 inch |
| 像素 | 水平: 3.75 µm, 垂直: 3.75 µm |
| 镜头接口 | C/CS |
| 接口 (电子) | |
| 接口 | USB 3.0 |
| 供应电压 | 4.5 VDC 至 5.5 VDC |
| 消耗电流 | 大约 250 mA @ 5 VDC |
| 自动光圈控制 | |
| 触发器 | |
| 输入/输出 | |
| 接口 (机械) | |
| 尺寸 | 高: 29 mm, 宽: 29 mm, 长: 43 mm |
| 重量 | 65 g |
| 调整 | |
| 快门 | 0.1 ms 至 1 s |
| 增益 | 0 dB 至 9 dB |
| 环境 | |
| 温度 (作业) | -5 °C 至 45 °C |
| 温度 (储存) | -20 °C 至 60 °C |
| 湿度 (作业) | 20 % 至 80 % (非冷凝) |
| 湿度 (储存) | 20 % 至 95 % (非冷凝) |
| 依实际情形调整更动 | |
 |
Industrial Cameras: Spectral Sensitivity | | 1.30 | 11月 2017 |
 |
Datasheet for onsemi MT9M021 CMOS Sensor | | 1.1 | 1月 2012 |
 |
The Imaging Source 2022 Catalog | | 2022.08 | 8月 2022 |
 |
DMK 23UM021 单色 相机 | | 20171218 | 12月 2017 |
 |
USB相机驱动程序 | | 2.9.8 |  |
8月 2019 |
 |
IC Imaging Control C++类库(C++项目适用) | | 3.5.7 | |
12月 2022 |
 |
IC Imaging Control .NET組件(C#和VB.NET项目适用) | | 3.5.7 | |
12月 2022 |
 |
IC Imaging Control C 范例 | | 3.4.0.51 | |
11月 2017 |
 |
IC Barcode - 1D and 2D Barcode Reader for IC Imaging Control | | 1.1.0.704 | |
3月 2021 |
 |
IC Barcode for Linux AMD64/x64 | | 1.1.0.703 |  |
3月 2021 |
 |
IC Barcode for Linux ARM 64 Bit | | 1.1.0.703 | |
3月 2021 |
 |
tiscamera Camera Library for Ubuntu 18.04 and 22.04 64 Bit on x64 Architecture | | 1.1.0.4139 | |
4月 2023 |
 |
tiscamera Camera Library for Ubuntu 20.04 64 Bit on x64 Architecture | | 1.1.0.4139 | |
4月 2023 |
 |
tiscamera Camera Library for ARM 64 Ubuntu 18.04 and 22.04 64 Bit | | 1.1.0.4139 | |
4月 2023 |
 |
tiscamera Camera Library for ARM 64 Ubuntu 20.04 64 Bit | | 1.1.0.4139 | |
4月 2023 |
 |
tiscamera Development Package | | 1.1.0.4139 | |
4月 2023 |
 |
IC Capture - Image Acquisition | | 2.5.1557.4007 | |
5月 2023 |
 |
IC Measure - 手动式屏幕测量和图像采集 | | 3.0.0.503 | |
6月 2023 |
 |
IC Measure for AMD 64 Linux | | 3.0.0.503 | |
6月 2023 |
 |
IC Measure for ARM 64 Linux | | 3.0.0.503 | |
6月 2023 |
 |
tcamdutils for Linux on x64 | | 1.0.0.560 | |
6月 2022 |
 |
tcamdutils for Linux ARM64 | | 1.0.0.560 | |
6月 2022 |
 |
tcamdutils-cuda GPU Enhanced Processing on NVIDIA® Tegra | | 1.2.0.397 | |
7月 2022 |
 |
tcamtegrasrc for MIPI and FPD Link Cameras on NVIDIA® Tegra | | 1.2.0.398 | |
7月 2022 |
 |
tiscamera Linux 32 Bit Camera Library for ARMHF Architecture | | 1.1.0.4139 | |
4月 2023 |
 |
tcamdutils 32 Bit for Raspberry PI OS | | 1.0.0.560 | |
6月 2022 |
 |
Raspberry PI GStreamer Source for The Imaging Source MIPI Cameras | | 1.3.0.662 | |
1月 2023 |
 |
tcamprop for Raspberry PI OS | | 0.1.0 | |
3月 2021 |
|
tiscamera Camera Library for Ubuntu 18.04 and 22.04 64 Bit on x64 Architecture | | 1.1.0.4139 | |
4月 2023 |
|
tiscamera Camera Library for Ubuntu 20.04 64 Bit on x64 Architecture | | 1.1.0.4139 | |
4月 2023 |
|
tiscamera Camera Library for ARM 64 Ubuntu 18.04 and 22.04 64 Bit | | 1.1.0.4139 | |
4月 2023 |
|
tiscamera Camera Library for ARM 64 Ubuntu 20.04 64 Bit | | 1.1.0.4139 | |
4月 2023 |
 |
IC Imaging Control TWAIN驱动扩展软件 | | 3.0.0.144 | |
2月 2021 |
 |
Cognex VisionPro AIK扩展软件 | | 3.4.2.0 | |
7月 2019 |
 |
IC Imaging Control LabVIEW扩展套件 | | 3.4.0.41 | |
9月 2019 |
 |
IC Imaging Control Matlab R2013b,R2014扩展软件 | | 3.4.0.58 | |
11月 2017 |
 |
NeuroCheck 6.2 ─ IC NeuroCheck Driver | | 1.1.0.122 | |
6月 2021 |
 |
IC Express - High-speed image capture into single image files | | 1.1.0.23 | |
7月 2019 |
 |
Processor Idle State Manager | | 2.2.0.2 | |
3月 2014 |
 |
Hot Pixel Correction (画素修复工具) | | 4.0. | |
7月 2019 |
 |
IC Fullscreen Presenter - Video display on the entire screen | | 1.3.0.0 | |
1月 2023 |
 |
IC Line Profiler | | 1.1.0.9 | |
8月 2014 |
 |
Footswitch software for IC Capture | | 1.0.0.9 | |
9月 2014 |
 |
Demo Image for NVIDIA® Jetson Nano™ Development Kits | | 1.0.5 | |
2月 2022 |
 |
Demo Image for NVIDIA® Jetson Xavier NX™ Development Kits | | 1.0.5 | |
2月 2022 |
 |
Demo Image for Raspberry Pi 4 B Development Kits | | 1.0.0 | |
3月 2021 |
 |
DFG/USB2-lt转换器驱动程序 | | 1.2.0.17 | |
8月 2011 |
 |
DFG/HDSDI驱动程序 | | 2.9.5 | |
4月 2018 |
 |
IEEE1394b相机驱动程序 | | 5.0.13.327 | |
3月 2014 |
 |
IEEE1394a相机驱动程序 | | 4.4.0.1 | |
6月 2011 |
 |
Video-to-FireWire转换器驱动程序 | | 4.2.0.1 | |
2月 2011 |
 |
Scan2Docx | | 1.1.0.883 | |
2月 2015 |
 |
Scan2Docx OCR | | 1.1.0.883 | |
2月 2015 |
 |
IC 3D -人性化三维校正；深度估测及三维可视化 | | 1.1 | |
8月 2018 |
 |
IC 3D SDK - 透过C及C++程序数据库进行立体深度估测 | | 1.1 | |
8月 2018 |
 |
IC Imaging Control ActiveX | | 3.2.0.0 | |
7月 2012 |
 |
IC Imaging Control ActiveX Runtime Setup | | 3.2.0.0 | |
7月 2012 |
 |
IC Imaging Control - 范例 | | 3.3 | |
8月 2014 |
 |
IC Imaging Control Matlab 10.0 R2010扩展软件 | | 1.1.0.0 | |
7月 2013 |
 |
NeuroCheck 6.0 ─ IC NeuroCheck Driver | | 1.0.0.51 | |
9月 2014 |
 |
NeuroCheck 6.1 ─ IC NeuroCheck Driver | | 1.1.0.69 | |
5月 2018 |
 |
MIPI Sensor Drivers for NVIDIA® JetPack Version 4.4 | | 2.2.11-1 | |
12月 2021 |
 |
MIPI Sensor Drivers for NVIDIA® JetPack Version 4.4.1 | | 2.2.11-1 | |
12月 2021 |
 |
tis-tegra-filters for NVIDIA® Tegra | | 1.1.1 | |
12月 2021 |
