| 特性概要 | |
| 视觉标准 |  |
| 动态范围 | 10 bit |
| 分辨率 | 1,920×1,200 (2.3 MP) |
| 帧率 | 100 fps |
| 视频输出格式 | 8-Bit Monochrome, 10-Bit Packed Monochrome, 16-Bit Monochrome |
| 接口 (光学) | |
| 传感器类型 | CMOS |
| 传感器规格 | onsemi AR0234CS |
| 快门 | 全局 |
| 规格 | 1/2.6 inch |
| 像素 | 水平: 3 µm, 垂直: 3 µm |
| 镜头接口 | C/CS |
| 接口 (电子) | |
| 接口 | USB 3.1 |
| 供应电压 | 4.75 VDC 至 5.25 VDC |
| 消耗电流 | 大约 tbd mA @ 5 VDC |
| 自动光圈控制 | |
| 触发器 | |
| 输入/输出 | |
| 接口 (机械) | |
| 尺寸 | 高: 36 mm, 宽: 36 mm, 长: 25 mm |
| 重量 | 70 g |
| 调整 | |
| 快门 | 50 µs 至 0.25 s |
| 增益 | 0 dB 至 6.92 dB |
| 环境 | |
| 外壳温度 (工作) | -5 °C 至 50 °C |
| 温度 (储存) | -20 °C 至 80 °C |
| 湿度 (作业) | 20 % 至 80 % (非冷凝) |
| 湿度 (储存) | 20 % 至 95 % (非冷凝) |
| 依实际情形调整更动 | |
 |
Industrial Cameras: Spectral Sensitivity | | 1.30 | 11月 2017 |
 |
Dimensional Diagrams for 27, 33, 33e, 37, 38 Series | | 2.0 | 12月 2017 |
 |
Datasheet for onsemi AR0234CS CMOS Sensor | | 1.0 | 2月 2023 |
 |
STEP File DxK 37AU CS-Mount (154-13-70) | | 1.0 | 1月 2018 |
 |
STEP File DxK 37AU C-Mount (154-13-72) | | 1.0 | 1月 2018 |
 |
The Imaging Source 2022 Catalog | | 2022.08 | 8月 2022 |
 |
DMK 37AUR0234 技术手册 | 新的 | 1.1 | 8月 2023 |
 |
