DFK AFU050-L34

USB 2.0 color autofocus camera

DFK AFU050-L34 - USB 2.0 color autofocus camera
DFK AFU050-L34 - USB 2.0 color autofocus camera
Integrated lens
  • 1/4 inch CMOS sensor
  • 2,592×1,944 (5 MP), up to 60 fps
  • Rolling shutter
  • Image enhancement
  • Manufactured by The Imaging Source
  • Windows and Linux software included


General behavior
Video formats @ frame rate (maximum) 2,592×1,944 (5 MP) MJPG @ 15 fps
1,920×1,080 (2.1 MP) MJPG @ 30 fps
1,280×720 (0.9 MP) MJPG @ 60 fps
Interface (optical)
IR cut filter
Sensor type CMOS
Shutter rolling
Format 1/4 inch
Pixel size H: 1.4 µm, V: 1.4 µm
Focal length 3.4 mm
F-Stop 2.8
MOD 10 cm
Focus One touch
Interface (electrical)
Interface USB 2.0 (forwards compatible)
Supply voltage 4.5 VDC to 5.5 VDC
Current consumption approx 250 mA @ 5 VDC
Auto iris control
Trigger
I/Os
Interface (mechanical)
Dimensions H: 36 mm, W: 36 mm, L: 18 mm
Mass 65 g
Adjustments
Shutter 1/5,000 s to 1 s
Gain ISO 50 dB to ISO 3200 dB
White balance presets: light bulb, daylight color, fluorescent light, clear sky, cloudy sky, neutral color fluorescent light, light bulb color fluorescent light
modes: red adjustment, blue adjustment
Image processing modes: sharpness, brightness, contrast
Color processing modes: saturation, hue
Environmental
Temperature (operating) -5 °C to 55 °C
Temperature (storage) -20 °C to 60 °C
Humidity (operating) 20 % to 80 % (non-condensing)
Humidity (storage) 20 % to 95 % (non-condensing)
Subject to change
Whitepapers about Cameras
Industrial Cameras: Spectral Sensitivity Industrial Cameras: Spectral Sensitivity 1.30 November 15, 2017
Automatic White Balance Automatic White Balance 1.0 September 24, 2015
Dimensional Diagrams
Dimensional Diagrams for 21, 22, 23, 24, 42, 72, Autofocus and Zoom Series Dimensional Diagrams for 21, 22, 23, 24, 42, 72, Autofocus and Zoom Series 1.14 December 15, 2017
Subject to change
Device Drivers
Device Driver for USB Cameras Device Driver for USB Cameras 2.9.5 May 4, 2018
Software Development Kits (SDKs)
IC Imaging Control .NET Component for C#, VB.NET, C++ Class Library for C++ projects IC Imaging Control .NET Component for C#, VB.NET, C++ Class Library for C++ projects 3.4.0.2744 October 23, 2018
IC 3D SDK - C, C++ library for stereo depth estimation IC 3D SDK - C, C++ library for stereo depth estimation 1.1 August 15, 2018
IC Imaging Control C Library IC Imaging Control C Library 3.4.0.51 November 23, 2017
IC Imaging Control ActiveX IC Imaging Control ActiveX 3.2.0.0 July 16, 2012
IC Imaging Control ActiveX Runtime Setup IC Imaging Control ActiveX Runtime Setup 3.2.0.0 July 16, 2012
Programming Samples
IC Barcode - 1D and 2D barcode reader for IC Imaging Control IC Barcode - 1D and 2D barcode reader for IC Imaging Control 1.0.0.580 November 2, 2018
IC Imaging Control - Sample Library IC Imaging Control - Sample Library 3.3 August 21, 2014
Extensions
LabVIEW Extension for IC Imaging Control LabVIEW Extension for IC Imaging Control 3.4.0.40 November 29, 2018
IC NeuroCheck Driver for NeuroCheck 6.1 IC NeuroCheck Driver for NeuroCheck 6.1 1.1.0.69 May 28, 2018
IC Matlab Plugin for Matlab R2013b and higher versions IC Matlab Plugin for Matlab R2013b and higher versions 3.4.0.58 November 23, 2017
TWAIN Source for IC Imaging Control TWAIN Source for IC Imaging Control 3.0.0.124 June 19, 2017
IC NeuroCheck Driver for NeuroCheck 6.0 IC NeuroCheck Driver for NeuroCheck 6.0 1.0.0.51 September 29, 2014
IC Matlab Plugin for Matlab 10.0 R2010 IC Matlab Plugin for Matlab 10.0 R2010 1.1.0.0 July 29, 2013
Cognex VisionPro AIK Plugin for IC Imaging Control Cognex VisionPro AIK Plugin for IC Imaging Control 3.2.0.3 May 28, 2013
End User Software
IC Measure - manual on-screen image measurement and image acquisition IC Measure - manual on-screen image measurement and image acquisition 2.0.0.133 October 8, 2018
IC 3D - User friendly stereo calibration, depth estimation and 3D visualization IC 3D - User friendly stereo calibration, depth estimation and 3D visualization 1.1 August 15, 2018
IC Capture - image acquisition IC Capture - image acquisition 2.4.642.2631 February 9, 2017
Scan2Voice Scan2Voice 2.4.2.960 June 21, 2016
Scan2Docx Scan2Docx 1.1.0.883 February 3, 2015
Scan2Docx OCR Scan2Docx OCR 1.1.0.883 February 3, 2015
Footswitch software for IC Capture Footswitch software for IC Capture 1.0.0.9 September 22, 2014
IC Line Profiler IC Line Profiler 1.1.0.9 August 1, 2014
IC Fullscreen Presenter IC Fullscreen Presenter 1.0.0.0 June 6, 2014
Software Tools
Hot Pixel Correction Hot Pixel Correction 4.0.0.553 July 2, 2014
Processor Idle State Manager Processor Idle State Manager 2.2.0.2 March 12, 2014
Subject to change
Cables
CA-USB20-AmB-BLS/5 CA-USB20-AmB-BLS/5 USB 2.0 cable, 5 m in length
Subject to change
