47G Series

GigE Board Cameras

The Imaging Source's new GigE board-level cameras feature a single-board design with an angled RJ45 connector, delivering an especially compact form factor, measuring just 36 x 36 x 18 mm. With robust data transmission and support for cable lengths up to 100 meters, the GigE board-level cameras ensure stable connectivity and flexible positioning in diverse environments.

47G Series

Reset Filter

Product Code MP Resolution FPS Format Sensor Mono/Color Shutter Pixel Size Trigger I/O Auto-Iris
DMM 47GX900 DMM 47GX900 3.1 MP 2,048×1,536 36 1/3.1 " IMX900 Global 2.25 µm ​ ​ ​
DMM 47GX900-ML DMM 47GX900-ML 3.1 MP 2,048×1,536 36 1/3.1 " IMX900 Global 2.25 µm ​ ​ ​
DMM 47GX900-MLP DMM 47GX900-MLP 3.1 MP 2,048×1,536 36 1/3.1 " IMX900 Global 2.25 µm ​ ​ ​
DMM 47GX900-P DMM 47GX900-P 3.1 MP 2,048×1,536 36 1/3.1 " IMX900 Global 2.25 µm ​ ​ ​
DMM 47GX568 DMM 47GX568 5 MP 2,448×2,048 24 1/1.8 " IMX568 Global 2.74 µm ​ ​ ​ **
DMM 47GX568-ML DMM 47GX568-ML 5 MP 2,448×2,048 24 1/1.8 " IMX568 Global 2.74 µm ​ ​ ​ **
DMM 47GX568-MLP DMM 47GX568-MLP 5 MP 2,448×2,048 24 1/1.8 " IMX568 Global 2.74 µm ​ ​ ​ **
DMM 47GX568-P DMM 47GX568-P 5 MP 2,448×2,048 24 1/1.8 " IMX568 Global 2.74 µm ​ ​ ​ **
DMM 47GR0521 DMM 47GR0521 5 MP 2,592×1,944 22 1/2.5 " AR0521 Rolling 2.2 µm ​ ​ ​
DMM 47GR0521-ML DMM 47GR0521-ML 5 MP 2,592×1,944 22 1/2.5 " AR0521 Rolling 2.2 µm ​ ​ ​
DMM 47GR0521-MLP DMM 47GR0521-MLP 5 MP 2,592×1,944 22 1/2.5 " AR0521 Rolling 2.2 µm ​ ​ ​
DMM 47GR0521-P DMM 47GR0521-P 5 MP 2,592×1,944 22 1/2.5 " AR0521 Rolling 2.2 µm ​ ​ ​
DMM 47GR2020 DMM 47GR2020 19.7 MP 5,120×3,840 6 1/1.8 " AR2020 Rolling 1.4 µm ​ ​ ​ *
DMM 47GR2020-ML DMM 47GR2020-ML 19.7 MP 5,120×3,840 6 1/1.8 " AR2020 Rolling 1.4 µm ​ ​ ​ *
DMM 47GR2020-MLP DMM 47GR2020-MLP 19.7 MP 5,120×3,840 6 1/1.8 " AR2020 Rolling 1.4 µm ​ ​ ​ *
DMM 47GR2020-P DMM 47GR2020-P 19.7 MP 5,120×3,840 6 1/1.8 " AR2020 Rolling 1.4 µm ​ ​ ​ *
DFM 47GX900 DFM 47GX900 3.1 MP 2,048×1,536 36 1/3.1 " IMX900 Global 2.25 µm ​ ​ ​
DFM 47GX900-ML DFM 47GX900-ML 3.1 MP 2,048×1,536 36 1/3.1 " IMX900 Global 2.25 µm ​ ​ ​
DFM 47GX900-MLP DFM 47GX900-MLP 3.1 MP 2,048×1,536 36 1/3.1 " IMX900 Global 2.25 µm ​ ​ ​
DFM 47GX900-P DFM 47GX900-P 3.1 MP 2,048×1,536 36 1/3.1 " IMX900 Global 2.25 µm ​ ​ ​
DFM 47GX568 DFM 47GX568 5 MP 2,448×2,048 24 1/1.8 " IMX568 Global 2.74 µm ​ ​ ​ **
DFM 47GX568-ML DFM 47GX568-ML 5 MP 2,448×2,048 24 1/1.8 " IMX568 Global 2.74 µm ​ ​ ​ **
DFM 47GX568-MLP DFM 47GX568-MLP 5 MP 2,448×2,048 24 1/1.8 " IMX568 Global 2.74 µm ​ ​ ​ **
DFM 47GX568-P DFM 47GX568-P 5 MP 2,448×2,048 24 1/1.8 " IMX568 Global 2.74 µm ​ ​ ​ **
DFM 47GR0521 DFM 47GR0521 5 MP 2,592×1,944 22 1/2.5 " AR0521 Rolling 2.2 µm ​ ​ ​
DFM 47GR0521-ML DFM 47GR0521-ML 5 MP 2,592×1,944 22 1/2.5 " AR0521 Rolling 2.2 µm ​ ​ ​
DFM 47GR0521-MLP DFM 47GR0521-MLP 5 MP 2,592×1,944 22 1/2.5 " AR0521 Rolling 2.2 µm ​ ​ ​
DFM 47GR0521-P DFM 47GR0521-P 5 MP 2,592×1,944 22 1/2.5 " AR0521 Rolling 2.2 µm ​ ​ ​
DFM 47GR2020 DFM 47GR2020 19.7 MP 5,120×3,840 6 1/1.8 " AR2020 Rolling 1.4 µm ​ ​ ​ *
DFM 47GR2020-ML DFM 47GR2020-ML 19.7 MP 5,120×3,840 6 1/1.8 " AR2020 Rolling 1.4 µm ​ ​ ​ *
DFM 47GR2020-MLP DFM 47GR2020-MLP 19.7 MP 5,120×3,840 6 1/1.8 " AR2020 Rolling 1.4 µm ​ ​ ​ *
DFM 47GR2020-P DFM 47GR2020-P 19.7 MP 5,120×3,840 6 1/1.8 " AR2020 Rolling 1.4 µm ​ ​ ​ *

** Coming soon* Prototypes available

Subject to change.

Features

  • CMOS sensors: CMOS (Rolling), Pregius S (Global)
  • Resolutions: 3.1 MP - 19.7 MP
  • Frame rates: 6 FPS - 36 FPS
  • Interface: GigE Interface (RJ45)
  • Trigger and I/O: Yes
  • OEM Cameras: OEM applications and co-branding for customer projects
  • Software: The Imaging Source authors and supports device drivers, software development kits (SDKs), end user software, programming samples, extensions, and tools by for Windows, Linux x86 and Linux ARM.
  • Warranty: 3-year warranty with continuous support
