DFM 37UX273-ML

37U Series

​ Get Quotation

  • 37U Series Color Board Camera
  • USB 3.1 Interface, Power via USB
  • 1/2.9 inch Sony CMOS Pregius IMX273 Sensor
  • 1,440×1,080 (1.6 MP), up to 238 fps
  • Pixel Size: H: 3.45 µm, V: 3.45 µm
  • Global Shutter
  • Trigger and I/O Inputs
  • Only 30×30×15 mm
  • Specification
  • Documentation
  • Downloads
  • Cables
  • Optics
General Behavior
Vision Standard GigE Vision
Dynamic Range 10 bit
Resolution 1,440×1,080 (1.6 MP)
Frame Rate 238 fps
Video Output Format 8-Bit Bayer (RG), 12-Bit Bayer Packed (RG), 16-Bit Bayer (RG)
Interface (Optical)
Sensor Type CMOS Pregius
Sensor Specification ​ Sony IMX273
Shutter Global
Format 1/2.9 inch
Pixel Size H: 3.45 µm, V: 3.45 µm
Sensor Size H: 5,0 mm, V: 3,7 mm
Sensor Diagonal 6,2 mm
Lens Mount M12x0.5, optional
Interface (Electrical)
Interface USB 3.1, Power via USB
Supply Voltage 4.75 VDC to 5.25 VDC
Current Consumption Approx. 380 mA @ 5 VDC
Auto-Iris Control ​
Trigger ​
I/O ​
Interface (Mechanical)
Dimensions H: 30 mm, W: 30 mm, L: 15 mm
Mass 7 g
Adjustments
Shutter 1 µs to 30 s
Gain 0 dB to 48 dB
Shock & Vibration
Vibration, Sinusoidal DIN EN 60068-2-6:2008-10
Vibration, Broadband Random DIN EN 60068-2-64:2020-09
Shock DIN EN 60068-2-27:2010-02
Environmental
Temperature (Operating) -5 °C to 45 °C
Temperature (Storage) -20 °C to 60 °C
Humidity (Operating) 20 % to 80 % (non-condensing)
Humidity (Storage) 20 % to 95 % (non-condensing)
Subject to change.
