DFK 37BUX290

37U Series

Please sign in or register an account to view pricing.

​ Get Quotation

  • 37U Series Color Industrial Camera
  • USB 3.1 Interface, Power via USB
  • 1/2.8 inch Sony CMOS STARVIS IMX290 Sensor
  • 1,920×1,080 (2.1 MP), up to 143 fps
  • Pixel Size: H: 2.9 µm, V: 2.9 µm
  • Sensor Size: 5,6 mm x 3,1 mm
  • Sensor Diagonal: 6,4 mm
  • Rolling Shutter
  • Trigger and I/O Inputs
  • Only 36×36×25 mm
  • Specification
  • Documentation
  • Downloads
  • Cables
  • Optics
General Behavior
Vision Standard GigE Vision
Dynamic Range 10 bit
Resolution 1,920×1,080 (2.1 MP)
Frame Rate 143 fps
Video Output Format 8-Bit Bayer (RG), 16-Bit Bayer (RG)
Ingress Protection
Protection Rating IP40 (with a suitable lens, a data cable with screw lock, and an I/O trigger cable installed)
Interface (Optical)
IR-Cut Filter ​ (available without IR-Cut Filter on request)
Sensor Type CMOS STARVIS
Sensor Specification ​ Sony IMX290
Shutter Rolling
Format 1/2.8 inch
Pixel Size H: 2.9 µm, V: 2.9 µm
Sensor Size H: 5,6 mm, V: 3,1 mm
Sensor Diagonal 6,4 mm
Lens Mount C/CS
Interface (Electrical)
Interface USB 3.1, Power via USB
Supply Voltage 4.75 VDC to 5.25 VDC
Current Consumption Approx. 260 mA @ 5 VDC
Auto-Iris Control ​
Trigger ​
I/O ​
Interface (Mechanical)
Dimensions H: 36 mm, W: 36 mm, L: 25 mm
Mass 70 g
Adjustments
Shutter 20 µs to 30 s
Gain 0 dB to 72 dB
Environmental
Housing Temperature (Operating) -5 °C to 50 °C
Temperature (Storage) -20 °C to 80 °C
Humidity (Operating) 20 % to 80 % (non-condensing)
Humidity (Storage) 20 % to 95 % (non-condensing)
Subject to change.
