- 37U Series Monochrome Industrial Camera
- USB 3.1 Interface, Power via USB
- 2/3 inch Sony CMOS Pregius IMX264 Sensor
- 2,448×2,048 (5 MP), up to 38 fps
- Pixel Size: H: 3.45 µm, V: 3.45 µm
- Sensor Size: 8,4 mm x 7,1 mm
- Sensor Diagonal: 11,0 mm
- Global Shutter
- Trigger and I/O Inputs
- Only 42×42×25 mm
- Specification
- Documentation
- Downloads
- Cables
- Optics
| General Behavior | |
| Vision Standard |  |
| Dynamic Range | 12 bit |
| Resolution | 2,448×2,048 (5 MP) |
| Frame Rate | 38 fps |
| Video Output Format | 8-Bit Monochrome, 16-Bit Monochrome |
| Ingress Protection | |
| Protection Rating | IP40 (with a suitable lens, a data cable with screw lock, and an I/O trigger cable installed) |
| Interface (Optical) | |
| Sensor Type | CMOS Pregius |
| Sensor Specification | Sony IMX264 |
| Shutter | Global |
| Format | 2/3 inch |
| Pixel Size | H: 3.45 µm, V: 3.45 µm |
| Sensor Size | H: 8,4 mm, V: 7,1 mm |
| Sensor Diagonal | 11,0 mm |
| Lens Mount | C/CS |
| Interface (Electrical) | |
| Interface | USB 3.1, Power via USB |
| Supply Voltage | 4.75 VDC to 5.25 VDC |
| Current Consumption | Approx. 360 mA @ 5 VDC |
| Auto-Iris Control | |
| Trigger | |
| I/O | |
| Interface (Mechanical) | |
| Dimensions | H: 42 mm, W: 42 mm, L: 25 mm |
| Mass | 76 g |
| Adjustments | |
| Shutter | 1 µs to 4 s |
| Gain | 0 dB to 48 dB |
| Environmental | |
| Housing Temperature (Operating) | -5 °C to 50 °C |
| Temperature (Storage) | -20 °C to 80 °C |
| Humidity (Operating) | 20 % to 80 % (non-condensing) |
| Humidity (Storage) | 20 % to 95 % (non-condensing) |
| Subject to change. | |
 |
DMK 37BUX264 Data Sheet | | 1.0 | Nov 2024 |
 |
