DYK 33GX250

33G Polarsens

Get Quotation

  • 33G Polarsens Unique Color Camera
  • GigE Interface (RJ45)
  • 2/3 inch Sony CMOS Pregius Polarsens IMX250MYR Sensor
  • 2,448×2,048 (5 MP), up to 24 fps
  • Pixel Size: H: 3.45 µm, V: 3.45 µm
  • Global Shutter
  • Trigger and I/O Inputs
  • Casing Compatible to Most Analog Cameras
  • Only 29×29×57 mm
  • Specification
  • Documentation
  • Downloads
  • Cables
General Behavior
Vision Standard GigE Vision
Dynamic Range 12 bit
Resolution 2,448×2,048 (5 MP)
Frame Rate 24 fps
Video Output Format 8-Bit Polarized Bayer (BG), 12-Bit Polarized Bayer Packed (BG), 16-Bit Polarized Bayer (BG)
Interface (Optical)
Sensor Type CMOS Pregius Polarsens
Sensor Specification Sony IMX250MYR
Shutter Global
Format 2/3 inch
Pixel Size H: 3.45 µm, V: 3.45 µm
Lens Mount C/CS
Interface (Electrical)
Interface Gigabit Ethernet (RJ45)
Supply Voltage 11 VDC to 13 VDC or POE: 48 VDC to 56 VDC
Current Consumption Approx. 400 mA @ 12 VDC
Auto-Iris Control
Trigger
I/O
Interface (Mechanical)
Dimensions H: 29 mm, W: 29 mm, L: 57 mm
Mass 65 g
Adjustments
Shutter 20 µs to 30 s
Gain 0 dB to 48 dB
Environmental
Housing Temperature (Operating) -5 °C to 50 °C
Temperature (Storage) -20 °C to 80 °C
Humidity (Operating) 20 % to 80 % (non-condensing)
Humidity (Storage) 20 % to 95 % (non-condensing)
Subject to change.
