DFK 33UP1300

33U Series

Get Quotation

  • 33U Series Color Industrial Camera
  • USB 3.0 Interface
  • 1/2 inch onsemi CMOS Python PYTHON 1300 Sensor
  • 1,280×1,024 (1.3 MP), up to 210 fps
  • Pixel Size: H: 4.8 µm, V: 4.8 µm
  • Global Shutter
  • Trigger and I/O Inputs
  • Only 29×29×43 mm
  • Specification
  • Documentation
  • Downloads
  • Cables
General Behavior
Vision Standard GigE Vision
Dynamic Range 10 bit
Resolution 1,280×1,024 (1.3 MP)
Frame Rate 210 fps
Video Output Format 8-Bit Monochrome, 8-Bit Bayer (RG), 10-Bit Bayer Packed (RG), 16-Bit Bayer (RG), YUV 4:2:2, YUV 4:1:1, RGB24
Interface (Optical)
IR-Cut Filter
Sensor Type CMOS Python
Sensor Specification onsemi PYTHON 1300
Shutter Global
Format 1/2 inch
Pixel Size H: 4.8 µm, V: 4.8 µm
Lens Mount C/CS
Interface (Electrical)
Interface USB 3.0
Supply Voltage 4.75 VDC to 5.25 VDC
Current Consumption Approx. 680 mA @ 5 VDC
Auto-Iris Control
Trigger
I/O
Interface (Mechanical)
Dimensions H: 29 mm, W: 29 mm, L: 43 mm
Mass 65 g
Adjustments
Shutter 50 µs to 10 s
Gain 0 dB to 9.21 dB
Environmental
Housing Temperature (Operating) -5 °C to 50 °C
Temperature (Storage) -20 °C to 80 °C
Humidity (Operating) 20 % to 80 % (non-condensing)
Humidity (Storage) 20 % to 95 % (non-condensing)
Subject to change.

The Imaging Source Catalog New 2024.05 May 2024
