DMK 33UX226

33U Series

Get Quotation

  • 33U Series Monochrome Industrial Camera
  • USB 3.0 Interface
  • 1/1.7 inch Sony CMOS STARVIS IMX226 Sensor
  • 4,000×3,000 (12 MP), up to 30 fps
  • Pixel Size: H: 1.85 µm, V: 1.85 µm
  • Rolling Shutter
  • Trigger and I/O Inputs
  • Only 29×29×43 mm
  • Specification
  • Documentation
  • Downloads
  • Cables
General Behavior
Vision Standard GigE Vision
Dynamic Range 12 bit
Resolution 4,000×3,000 (12 MP)
Frame Rate 30 fps
Video Output Format 8-Bit Monochrome, 12-Bit Packed Monochrome, 16-Bit Monochrome
Interface (Optical)
Sensor Type CMOS STARVIS
Sensor Specification Sony IMX226
Shutter Rolling
Format 1/1.7 inch
Pixel Size H: 1.85 µm, V: 1.85 µm
Lens Mount C/CS
Interface (Electrical)
Interface USB 3.0
Supply Voltage 4.75 VDC to 5.25 VDC
Current Consumption Approx. 660 mA @ 5 VDC
Auto-Iris Control
Trigger
I/O
Interface (Mechanical)
Dimensions H: 29 mm, W: 29 mm, L: 43 mm
Mass 65 g
Adjustments
Shutter 50 µs to 300 s
Gain 0 dB to 27.04 dB
Environmental
Housing Temperature (Operating) -5 °C to 50 °C
Temperature (Storage) -20 °C to 80 °C
Humidity (Operating) 20 % to 80 % (non-condensing)
Humidity (Storage) 20 % to 95 % (non-condensing)
Subject to change.
