DMK 38UX304

38U Series

Get Quotation

  • 38U Series Monochrome Industrial Camera
  • USB 3.1 Interface
  • 1.1 inch Sony CMOS Pregius IMX304 Sensor
  • 4,096×3,000 (12.3 MP), up to 26 fps
  • Pixel Size: H: 3.45 µm, V: 3.45 µm
  • Global Shutter
  • Trigger and I/O Inputs
  • Only 29×44×60 mm
  • Specification
  • Documentation
  • Downloads
General Behavior
Vision Standard GigE Vision
Dynamic Range 12 bit
Resolution 4,096×3,000 (12.3 MP)
Frame Rate 26 fps
Video Output Format 8-Bit Monochrome, 12-Bit Packed Monochrome, 16-Bit Monochrome
Interface (Optical)
Sensor Type CMOS Pregius
Sensor Specification Sony IMX304
Shutter Global
Format 1.1 inch
Pixel Size H: 3.45 µm, V: 3.45 µm
Lens Mount C (CS optional)
Interface (Electrical)
Interface USB 3.1
Supply Voltage 4.75 VDC to 5.25 VDC
Current Consumption Approx. 810 mA @ 5 VDC
Auto-Iris Control
Trigger
I/O
Interface (Mechanical)
Dimensions H: 29 mm, W: 44 mm, L: 60 mm
Mass 110 g
Adjustments
Shutter 2 µs to 4 s
Gain 0 dB to 48 dB
Environmental
Temperature (Operating) -5 °C to 45 °C
Temperature (Storage) -20 °C to 60 °C
Humidity (Operating) 20 % to 80 % (non-condensing)
Humidity (Storage) 20 % to 95 % (non-condensing)
Subject to change.
